Heavy-Duty Steel Edge Protection Barrier with Anti-Corrosion
Coating for Construction Site Perimeters
Built to withstand the rigors of construction sites, this edge
protection barrier features a heavy-duty steel frame—crafted from
high-gauge, hot-rolled steel—that delivers unmatched strength. The
robust structure resists bending, warping, or impact damage from
heavy machinery, falling debris, or frequent worker contact.
Designed specifically for perimeter use, it forms a formidable
physical barrier along elevated edges (rooftops, scaffolding, open
floors) and site boundaries, reliably preventing accidental falls
and unauthorized access.
To thrive in harsh construction environments—exposed to rain, mud,
salt, and industrial chemicals—the barrier is treated with a
multi-layer anti-corrosion coating. A base layer of hot-dip
galvanization creates a zinc shield against rust, while a top layer
of powder coating adds scratch resistance and UV protection. This
dual defense ensures long-term durability, even in outdoor or
high-moisture conditions, reducing maintenance needs and extending
the barrier’s lifespan across multiple projects.
Engineered for construction site perimeters, it combines fall
prevention with boundary control. The barrier stands at a standard
42+ inches in height (meeting OSHA/EN standards) and features
tightly spaced rails or mesh panels to block gaps, preventing
tools, debris, or workers from passing through. Its stability is
enhanced by reinforced base plates and optional ground anchors,
ensuring it stays firmly in place—even on uneven terrain or during
high winds common at construction sites.
Despite its heavy-duty build, this barrier prioritizes
practicality. Modular sections connect via quick-release pins or
boltless joints, allowing fast assembly and disassembly by a small
crew. When not in use, components stack compactly for efficient
transport and storage, making it ideal for moving between job
sites. Its reusability across projects adds value, eliminating the
need for disposable perimeter solutions.
Safety compliance is non-negotiable. The barrier meets strict
industry standards, including OSHA 1926.502 (construction fall
protection) and EN 13374 (temporary edge protection), ensuring it
passes inspections and reduces liability risks. High-visibility
color options (safety red, orange) and optional reflective strips
enhance visibility in low-light conditions, alerting workers and
equipment operators to perimeter edges—critical for busy
construction zones.
Our Edge Protection Barrier Specifications
| Wire Diameter | Mesh Size | Height | Length | Post | Thinckness | Color |
5mm 6mm 7mm | 50*100mm 50*150mm 100*200mm | 1.05m 1.10m | 1.3m--2.6m | 48mm | 1.5mm 1.8mm 2.0mm | Yellow Blue Red Other RAL color |
When ordering in large quantities, you have the option of
imprinting the customer's logo and colors.Various matching
accessories are available to provide solutions for various on-site
situations.
Our Edge Protection Barrier Cases:
we offer a wide range of safety solutions to reduce on site
accidents. Our pioneering edge protection barriers prevent
employees from injury. Whether they are working at ground level or
on elevated platforms, we have a selection of building site edge
protection safety measures to make sure they are protected while
they work.
Our Edge Protection Barrier advantage
1. Our products are versatile and durable - made from high quality
materials, hot-dipped galvanized and manufactured to the highest
standards of finish!
2. Our products are highly modular and simple to operate and
install.One-touch installation! Very convenient and effective!
3. High development capacity for innovative smart solutions
customized to customer needs
4. Our fence panels are curved at the top and bottom, and are
uniquely designed to provide maximum strength and prevent excessive
bending of the net.
5. The uniformity of the installation allows for maximum
supervision and control, thus maintaining a high level of safety at
all stages of construction.
No items will fall apart to prevent loss.Convenient and effective
packaging for long term product storage and easy transportation
